Honeywell VARIODYN D1 - 3 Planning and Configuration; System Overview

Installation Instruction VARIODYN
®
D1 System
FB 798663.GB0 / 05.19 9
3 Planning and configuration
The planning and configuration information below offers a quick overview of the proper use as well as the technical
capabilities of the VARIODYN
®
D1 System.
The specifications in the technical planning documents as well as the applicable standards, national regulations
and local requirements must always be complied with in the installation.
System Overview
The networkable, modular VARIODYN
®
D1 System is assembled from components into a building-specific
configuration. Special solutions can thus be implemented economically and effectively for buildings of different
sizes and for various alarm purposes.
call station
loudspeaker
DOM
PA1
PA2
Service PC / laptop
PA1
PA2
DOM
LAN
Ethernet
LIM
LIM
LIM
LIM
ETCS
VARIODYN
®
D1
Comprio / net
EOL
DOM
PA1
PA2
UIM
SCU
CD player
loudspeaker
call station
call station
Loop
Spur
Spur
amplifier
call station
Fig. 1: System overview (example of a networked system)
For security reasons only one independent D1 network (LAN) can be used
without a logical and/or
physical connection to the internet or another network.
The technical performance characteristics may be limited by standards, directives, and local
requirements.
