Installation Instruction VARIODYN
®
D1 System
74 FB 798663.GB0 / 05.19
7.7.3 Series 4XDx00 and 4XVx00
One DOM and one backup amplifier:
• Backup for 6 DOMs, each using one four-channel amplifier
CH1 OUT
1
4
2
5
3
6
1
4
2
5
3
6
CH2 OUT
CH3 OUT
1
4
2
5
3
6
1
4
2
5
3
6
CH4 OUT
IN
REP PA
1 2
1 2
3 4
3 4
DOM
(with main aplifiers)
DOM
(with backup amplifiers)
to additional
DOM
1
2

With a four-channel backup amplifier incl.
the backup cable RC 44
(Part No. 583444) up to 6 DOMs can be
substituted.
Use to connect the prefabricated cabling from four backup channels to four voice/data channels.
Fig. 67: Backup cable RC 44 VARIODYN
®
D1, 2 m (Part No. 583444) or 0.5 m (Part No. 583444.10)
