Honeywell VARIODYN D1 User Manual

Installation Instruction VARIODYN
®
D1 System
FB 798663.GB0 / 05.19 77
5 6
1
2
43
Fig. 71: Rear view

Terminals for max. tree DOM4-8 or 4-24 (24 V / 5 A)

Female appliance connector for 230 V AC nominal voltage

Terminals for output contact

Terminals for max. six Power Amplifiers (24 V / 40 A)

Temperature sensor

Terminals for Battery connection (+ / -)
 terminals for output contact
DIGITAL I/O DIGITAL I/O
GND 1 2 3 4 5 6 7 8 9 10 11 12
GND
GND
GND13 14
15 16 17 18
19
20
21
22
23
24
25 26 27 28 29 30 31 32 34 35
36
37
38
39
40
41
42
43
44
45 46 47 48
33
Output contacts
NC
-
NO
Mains
fault
Batterie
fault
Output
fault
NC
-
NO
NC
-
NO
UIM
