Honeywell VFD CORE

CHAPTER 12: DESCRIPTION OF PARAMETER SETTINGS
183 63-4528—04
• These parameters can be used with multi-function output (set to 35-38) for the specific requirement. When the fault occurs, the
corresponding terminals will be activated (It needs to convert binary value to decimal value to fill in Pr.06-22 to Pr.06-25)
a
06 - 22 Fault Output Option 1
a
06 - 23 Fault Output Option 2
a
06 - 24 Fault Output Option 3
a
06 - 25 Fault Output Option 4
Factory Setting: 0
Settings 0 to 65535 sec (refer to bit table for fault code)
Fault Code
Bit0 Bit1 Bit2 Bit3 Bit4 Bit5 Bit6
current Volt. OL SYS FBK EXI CE
0: No fault
1: Over-current during acceleration (ocA)
z
2: Over-current during deceleration (ocd)
z
3: Over-current during constant speed (ocn)
z
4: Ground fault (GFF)
z
5: IGBT short-circuit (occ)
z
6: Over-current at stop (ocS)
z
7: Over-voltage during acceleration (ovA)
z
8: Over-voltage during deceleration (ovd)
z
9: Over-voltage during constant speed (ovn)
z
10: Over-voltage at stop (ovS)
z
11: Low-voltage during acceleration (LvA)
z
12: Low-voltage during deceleration (Lvd)
z
13: Low-voltage during constant speed (Lvn)
z
14: Stop mid-low voltage (LvS)
z
15: Phase loss protection (OrP)
z
16: IGBT over-heat (oH1)
z
17: Capacitance over-heat (oH2)
z
18: tH1o (TH1 open)
z
19: tH2o (TH2 open)
z
20: Reserved
z
21: Drive over-load (oL)
z
22: Electronics thermal relay 1 (EoL1)
z
23: Electronics thermal relay 2 (EoL2)
z
24: Motor PTC overheat (oH3) (PTC)
z
25: Reserved
z
26: Over-torque 1 (ot1)
z
27: Over-torque 2 (ot2)
z
28: Low current (uC)
z
29: Reserved
30: Memory write-in error (cF1)
z
