Honeywell VFD CORE User Manual

97 63-4528—04
CHAPTER 11: SUMMARIES OF PARAMETER SETTINGS
System Parameters
NOTE: IM: Induction Motor; PM: Permanent Magnet Motor
Table 1. System Parameters
Parameter Function Setting
Factory
Setting
00-00 ID Code of the VFD
4: 230V, 1HP (0.75kW)
5: 460 V, 1HP (0.75kW)
6: 230V, 2HP (1.5kW)
7: 460 V, 2HP (1.5kW)
8: 230V, 3HP (2.2kW)
9: 460 V, 3HP (2.2kW)
10: 230V, 5HP (3.7kW)
11: 460 V, 5HP (3.7kW)
12: 230V, 7.5HP (5.5kW)
13: 460 V, 7.5HP (5.5kW)
14: 230V, 10HP (7.5kW)
15: 460V, 10HP (7.5kW)
16: 230V, 15HP (11kW)
17: 460V, 15HP (11kW)
18: 230V, 20HP (15kW)
19: 460V, 20HP (15kW)
20: 230V, 25HP (18.5kW)
21: 460V, 25HP (18.5kW)
22: 230V, 30HP (22kW)
23: 460V, 30HP (22kW)
24: 230V, 40HP (30kW)
25: 460V, 40HP (30kW)
26: 230V, 50HP (37kW)
27: 460V, 50HP (37kW)
28: 230V, 60HP (45kW)
29: 460V, 60HP (45kW)
30: 230V, 75HP (55kW)
31: 460V, 75HP (55kW)
32: 230V, 100HP (75kW)
33: 460V, 100HP (75kW)
34: 230V, 125HP(90kW)
35: 460V, 125HP (90kW)
37: 460V, 150HP (110kW)
39: 460V, 175HP(132kW)
41: 460V, 215HP(160kW)
43: 460V, 250HP(185kW)
45: 460V, 300HP(220kW)
47: 460V, 375HP(280kW)
49: 460V, 425HP(315kW)
51: 460V, 475HP(355kW)
53: 460V, 536HP(400kW)
93: 460V, 5.5HP (4.0kW)
Read
Only
00-01 Display VFD Rated Current
Display by models Read
Only
