Honeywell VFD CORE User Manual

87 63-4528—04
CHAPTER 9: SPECIFICATIONS
Table 1. 230V Series
Frame size A B C D E
Model HCRDAxxxxx1000T
1hp 2hp 3hp 5hp 7.5hp 10hp 15hp 20hp 25hp 30hp 40hp 50hp 60hp 75hp 100hp 125hp
Output Rating
Normal
“HVAC”
Duty -
Variable
Torque
Rated Output
Capacity (kVA) 2 3 4 6 8.4 12 18 24 30 36 42 58 72 86 110 128
Rated Output
Current (A) 5 7.5 10 15 21 31 46 61 75 90 105 146 180 215 276 322
Applicable
Motor Output
(kW)
0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37 45 55 75 90
Applicable
Motor Output
(HP)
1 2 3 5 7.5 10 15 20 25 30 40 50 60 75 100 125
Overload
tolerance 120% of rated current for 1 minute
Max. output
frequency (Hz) 600.00Hz (55KW~: 400.00Hz)
Carrier
Frequency
(kHz)
2~15kHz (8KHz) 2~10kHz (6kHz) 2~9kHz (4KHz)
Heavy
Duty -
Constant
Torque
Rated Output
Capacity (kVA)
1.8 2 3.2 4.4 6.8 10 13 20 26 30 36 48 58 72 86 102
Rated Output
Current (A)
4.6 5 8 11 17 25 33 49 65 75 90 120 146 180 215 255
Applicable
Motor Output
(kW)
0.4 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37 45 55 75
Applicable
Motor Output
(HP)
0.5 1 2 3 5 7.5 10 15 20 25 30 40 50 60 75 100
Overload
tolerance
120% of rated current for 1 minute, 160% of rated current for 3 seconds
Max. output
frequency (Hz)
600.00Hz(55KW~: 400.00Hz)
Carrier
Frequency
(kHz)
2~15kHz (8KHz) 2~10kHz (6kHz)` 2~9kHz(4KHz)
Input Rating
Input Current (A) Normal
Duty
6.4 9.6 15 22 25 35 50 65 83 100 116 146 180 215 276 322
Input Current (A) Heavy
Duty
3.9 6.4 12 16 20 28 36 52 72 83 99 124 143 171 206 245
Rated Voltage/Frequency 3-phase AC 200V~240V (-15% ~ +10%), 50/60Hz
Operating Voltage Range 170~265Vac
Frequency Tolerance 47~63Hz
Cooling method
Natural
Cooling
Fan Cooling
Braking Chopper Frame A,B,C: Built-in Frame D and above: Optional
DC choke Frame A, B,C: Optional Frame D and above: 3% built-in
EMI Filter Optional
