CHAPTER 4: WIRING
Fig. 1. Wiring Diagram for Frames A-C.
R(L1)
S(L2)
T(L3)
FWD
R(L1)
S(L2)
T(L3)
NFB
U(T1)
V(T2)
W(T3)
MOTOR
JUMPER
DC CHOKE
(OPTIONAL)
BREAKING RESISTOR
(OPTIONAL)
IM
3~
REV
MI1
FWD/STOP
REV/STOP
3 PHASE POWER IS PROVIDED
FUSE/NO FUSE BREAKER
FACTORY SETTING:
PNP SOURCE
PRESET SPD 1
PRESET SPD 2
PRESET SPD3
PRESET SPD 4
EXT F
A
ULT
FAULT RESET
NA
NA
MI3
MI2
MI4
MI5
MI6
MI7
MI8
MULTI FUNCTION
OUTPUT TERMINALS
RA1
RB1
RC1
RA2
RC2
RA3
RC3
250VAC/6A
30VDC/6A
30VDC/5A
MULTI FUNCTION OUTPUT
FREQUENCY TERMINALS
250VAC/5A
MULTI FUNCTION OUTPUT
FREQUENCY TERMINALS
250VAC/5A
30VDC/5A
DCM
SCM
S1
DIGITAL SIGNAL COMMON TERMINAL WHILE
USING INTERNAL POWER TO RUN SINK MODE
FACTORY
SETTING
POWER REMOVAL SAFETY FUNCTION
FOR EMERGENCY STOP
DIGITAL SIGNAL COMMON TERMINAL
+10V/20mA
0~10V/0~20mA
0 20mA/0~10V
ANALOG SIGNAL
COMMON TERMINAL
3
2
1
5KΩ
MAIN CIRCUIT (POWER)
TERMINALS
CONTROL
TERMINALS
SHIELDED
LEADS &
CABLES
+10V
AVI1
ACI
AVI2
ACM
AFM1
ACM
AFM2
ANALOG MULTI-FUNCTION
OUTPUT TERMINAL
0~10V/0~20mA
ANALOG SIGNAL
COMMON TERMINAL
ANALOG MULTI-FUNCTION
OUTPUT TERMINAL
0~10V/0~20mA
OPTION SLOT 1
OPTION SLOT 3
COMMUNICATION EXTENSION CARD
I/O & RELAY EXTENSION CARD
8 1
8 1
MODBUS RS-485
PIN 1~2, 7, 8:
RESERVED
PIN 3, 6: GND
PIN 4: SG
PIN 5: SG+
SG+
SG
M31490
0~+10V
COM
DCM
+24V
RA1 (RELAY OUT 1): RUN
RA2 (RELAY OUT 2): FAULT
RA3 (RELAY OUT 3): READY
MI: MULTIFUNCTION INPUT
AVI: ANALOGUE VOLTAGE INPUT
ACI: ANALOGUE CURRENT INPUT
+24V
