CHAPTER 12: DESCRIPTION OF PARAMETER SETTINGS
125 63-4528—04
NOTES:
1. It can display negative values when setting analog input bias (Pr.03-03~03-10).
Example: assume that AVI1 input voltage is 0V, Pr.03-03 is 10.0% and Pr.03-06 is 4 (Serve bias as the center).
2. Example: If REV, MI1 and MI6 are ON, the following table shows the status of the terminals.
0 means OFF, 1 means ON
MI10~MI15 are the terminals for extension cards (Pr.02-24~02-29).
If REV, MI1 and MI6 are ON, the value is 0000 0000 1000 0110 in binary and 0086h in HEX. When Pr.00-04 is set to “16” or “19,”
it will display “0086h” with LED U is ON on the keypad. The setting 16 is the status of digital input by Pr.02-11 setting and the
setting 19 is the corresponding CPU pin status of digital input. User can set to 16 to monitor digital input status and then set to 19
to check if the wire is normal.
NOTES:
3. Assume that RY1: Pr.02-13 is set to 9 (Drive ready). After applying the power to the VFD, if there is no other abnor-
mal status, the contact will be OFF. The display status will be shown as follows.
0 means OFF, 1 means ON
Meanwhile, if Pr.00-04 is set to 17 or 20, it will display in hexadecimal “0001h” with LED U is ON on the keypad. The setting 17 is
the status of digital output by Pr.02-16 setting and the setting 20 is the corresponding CPU pin status of digital output. User can
set 17 to monitor the digital output status and then set to 20 to check if the wire is normal.
• This parameter is to set coefficient gain in actual output frequency. Set Pr.00-04= 31 to display the calculation result on the
screen (calculation = output frequency * Pr.00-05).
16: The status of digital input (ON/OFF) refer to Pr.02-18 (i) (Refer to Note 3)
17: Display digital output status ON/OFF (Pr.02-15) (o) (refer to NOTE 4)
18: Display the multi-step speed that is executing (S)
19: The corresponding CPU pin status of digital input (d) (refer to NOTE 3)
20: The corresponding CPU pin status of digital output (0.) (refer to NOTE 4)
25: Overload counting (0.00~100.00%) (h.)
26: GFF Ground Fault (Unit: %)(G.)
27: DC Bus voltage ripple (Unit: Vdc)(r.)
28: Display PLC register D1043 data (C) display in hexadecimal
30: Display output of user defined (U)
31: H page x 00-05 Display user Gain (K)
Terminal MI15 MI14 MI13 MI12 MI11 MI10 MI8 MI7 MI6 MI5 MI4 MI3 MI2 MI1 REV FWD
Status0000000010000110
Terminal Reserved Reserved Reserved MO2 MO1 Reserved RY2 RY1
Status0000000000000 0 0 0 1
00 - v05 Coefficient Gain in Actual Output Frequency
Factory Setting: 0.00
Settings 0~160.00
00 - 06 Software version
Factory Setting: #.#
Settings Read Only
