Honeywell VFD CORE

CHAPTER 9: SPECIFICATIONS
63-4528—04 88
Table 2. 460V Series
Frame A B C D
Models HCRDCxxxxx1000T 1hp 2hp 3hp 5hp 7.5hp 10hp 15hp 20hp 25hp 30hp 40hp 50hp 60hp 75hp 100hp 125hp
Output Rating
Normal
“HVAC”
Duty -
Variable
Torque
Rated Output
Capacity (kVA) 2.4 2.9 4 6 9.6 11.2 18 24 29 36 45 57 73 88 115 143
Rated Output
Current (A) 3 3.7 5 7.5 12 14 22.5 30 36 45 56 72 91 110 144 180
Applicable Motor
Output (kW) 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37 45 55 75 90
Applicable Motor
Output (HP) 1 2 3 5 7.5 10 15 20 25 30 40 50 60 75 100 125
Overload
tolerance
120% of rated current for 1 minute
Max. output
frequency (Hz)
600.00Hz (90KW~: 400.00Hz)
Carrier Frequency
(kHz)
2~15kHz (8KHz) 2~10kHz (6kHz)
2~9
kHz
(4KHz
Heavy
Duty -
Constant
Torque
Rated Output
Capacity (kVA)
2.2 2.4 3.2 4.8 8.4 10 14 19 25 30 36 48 58 73 88 120
Rated Output
Current (A)
2.8 3 4 6 10.5 12 18 24 32 38 45 60 73 91 110 150
Applicable Motor
Output (kW)
0.4 0.75 1.5 2.2 4 5.5 7.5 11 15 18.5 22 30 37 45 55 75
Applicable Motor
Output (HP)
0.5 1 2 3 5 7.5 10 15 20 25 30 40 50 60 75 100
Overload
tolerance
120% of rated current for 1 minute;160% of rated current for 3 seconds
Max. output
frequency (Hz)
600.00Hz(90KW~: 400.00Hz)
Carrier Frequency
(kHz)
2~15kHz (8KHz) 2~10kHz (6kHz)
2~9
kHz
(4KHz
Input Rating
Input Current (A) Normal
Duty
4.3 5.4 7.4 11 18 20 25 33 39 47 58 76 91 110 144 180
Input Current (A) Heavy Duty
3.5 4.3 5.9 8.7 15.5 17 20 26 35 40 47 63 74 101 114 157
Rated Voltage/Frequency 3-phase AC 380V~480V (-15%~+10%), 50/60Hz
Operating Voltage Range 323~528Vac
Frequency Tolerance 47~63Hz
Cooling method Natural Cooling Fan Cooling
Braking Chopper
Frame A,B,C: Built-in
Frame D and above:
Optional
DC choke
Frame A, B,C: Optional
Frame D and above: 3%
DC built-in
EMI Filter
Frame A, B, C - EMI filter NOT built-in
Frame D and above:
Optional
