CHAPTER 12: DESCRIPTION OF PARAMETER SETTINGS
219 63-4528—04
3. Address list
Content Address Function
VFD Parameters GGnnH
GG means parameter group, nn means parameter number, for example, the
address of Pr 4-01 is 0401H.
Command
Write only
2000H
Bit0~3
0: No function
1: Stop
2: Run
3: Jog + Run
Bit4~5 00B: No function
01B: FWD
10B: REV
11B: Change direction
Bit6~7 00B: 1st accel/decel
01B: 2nd accel/decel
10B: 3rd accel/decel
11B: 4th accel/decel
Bit08~11 0000B: master speed
0001B: 1st accel/decel.
0010B: 2nd accel/decel
0011B: 3rd accel/decel
0100B: 4th accel/decel
0101B: 5th accel/decel
0110B: 6th accel/decel
0111B: 7th accel/decel
1000B: 8th accel/decel
1001B: 9th accel/decel
1010B: 10th accel/decel
1011B: 11th accel/decel
1100B: 12th accel/decel
1101B: 13th accel/decel
1110B: 14th accel/decel
1111B: 15th accel/decel
Bit12 1: enable bit06-10 function
Bit13~14 00B: No function
01B: operated by digital keypad
10B: operated by Pr.00-15 setting
11B: change operation source
Bit15 Reserved
2001H Frequency command
2002H Bit 0 Bit 0
Bit 1 Bit 1
Bit 2 Bit 2
Bit 3-15 Bit 3-15
Status monitor
Read only
2100H Error code: refer to Pr.06-16 to Pr.06-21
2119H Bit0 1: FWD command
Bit1 1: Operation status
Bit2 1: Jog command
Bit3 1: REV command
Bit4 1: REV command
Bit8 1: Master frequency Controlled by communication interface
Bit9 1: Master frequency controlled by analog signal
Bit10 1: Operation command controlled by communication interface
Bit11 1: Parameters have been locked
Bit12 1: enable to copy parameter from keypad
Bit13~15 Reserved
2102H Frequency command (F)
2103H Output frequency (H)
2104H Output current (AXXX.X)
2105H DC-BUS Voltage (UXXX.X)
2106H Output voltage (EXXX.X)
