Voyager XP User Guide 201
Guaranteed Performance
Standard Cable Pinouts
Note: The following pin assignments are not compatible with Honeywell legacy products.
Use of a cable with improper pin assignments may lead to damage to the unit. Use of
any cables not provided by the manufacturer may result in damage not covered by
your warranty.
Focus
Symbology
Near
Distance
Far
Distance
5 mil Code 39 in. 1 7.9
mm 25 200
10 mil Code 39 in. .2 13
mm 5 330
13 mil UPC-A in. .8 14.6
mm 20 370
20 mil Code 39 in. 1.2 17.9
mm 30 455
6.7 mil PDF417 in. 1 6.9
mm 25 175
10 mil PDF417 in. 1 10.2
mm 25 260
10 mil Data Matrix in. .6 6.1
mm 15 155
10 mil QR Code in. .4 6.3
mm 10 160
20 mil QR Code in. .4 12
mm 10 305
NYS DL in. 3.1 7.9
mm 80 200
