Voyager XP User Guide 13
Each barcode above also programs the following suffixes for each symbology:
* Suffixes programmed for Code 128 with IBM 4683 Port 5B, IBM 4683 Port 9B HHBCR-1, and IBM 4683
Port 17 Interfaces
**Suffixes programmed for Code 128 with IBM 4683 Port 9 HHBCR-2 Interface
RS485 Packet Mode
The following selection allows you to break up large barcode data into smaller
packets on an IBM POS terminal. To break up large barcodes into small packets,
scan the Packet Mode On barcode below. Scan the Packet Mode Off barcode if
you want large barcode data to be sent to the host in a single chunk. Default =
Packet Mode Off.
RS485 Packet Length
If you are using Packet mode, you can specify the size of the data “packet” that is
sent to the host. Scan the Packet Length barcode, then the packet size (from 20 -
256) from the Programming Chart, then Save. Default = 40.
Symbology Suffix Symbology Suffix
EAN 8 0C Code 39 00 0A 0B
EAN 13 16 Interleaved 2 of 5 00 0D 0B
UPC A 0D Code 128 * 00 0A 0B
UPC E 0A Code 128 ** 00 18 0B
MaxiCode 00 2F 0B
IBM Port 9B
HHBCR-2 Interface
