SPYDER MODEL 7 VAV CONTROLLER INSTALLATION INSTRUCTIONS
35 31-00475-01
Recognition of Sensor Failure of Sensor Inputs
The thresholds at which the sensor fails, that is, sensor breaks (SB) and short-circuits (SC), are recognized,
depending upon the given sensor type. In the event of a recognized sensor failure, the sensor assumes the safety
values configured in Table 29 on page 34. It lists the measurement ranges and the corresponding thresholds for the
recognized sensor failure for the various types of sensor:
NOTE:
In the case of temperatures lying outside the ranges, the lowest and highest value within the range, will be
communicated. Thus, a temperature of -51 °F will be communicated as “-50 °F.”
Table 30 Thresholds for Short-circuit (SC) and Sensor-break (SB) Recognition
I/O
Configuration
Measurement Range Recognition Thresholds
2 to 10 V 2 to 10 VDC 4 to 20 mA (without pull-up) SC: < 1.5 VDC 3 mA; SB: no recognition
10 k NTC Ω (Type II) -22 °F to +212 °F (-30 °C to +100 °C) SC: < 20 Ω; SB: < -94 °F (-70 °C)
20 k NTC Ω -58 °F to +302 °F (-50 °C to +150 °C) SC: < 20 Ω; SB: < -94 °F (-70 °C)
PT1000 -58 °F to +752 °F (-50 °C to + 400 °C) SC: < 775 Ω; SB: < -58 °F (-50 °C)
NI1000TK5000 -22 °F to +266 °F (-30 °C to +130 °C) SC: < 850 Ω; SB: < -58 °F (-30 °C)
PT100 -58 °F to +752 °F (-50 °C to +400 °C) -
PT3000 -58 °F to +302 °F (-50 °C to +150 °C) -
10K3A1 -40 °F to +257 °F (-40 °C to +125 °C) -
Nickel Class B DIN
43760 sensors
-76 °F to +752 °F (-60 °C to +169 °C) -
