SPYDER MODEL 7 VAV CONTROLLER INSTALLATION INSTRUCTIONS
31-00475-01 54
PT3000 Characteristics
Table 40 PT3000 Characteristics
Temp.
[°F]
Temp.
[°C]
Resistance
[KΩ]
Terminal
Voltage [V]
Temp.
[°F]
Temp.
[°C]
Resistance
[KΩ]
Terminal
Voltage
[V]
-58 -50 2.82 1.02 131 55 3.74 1.31
-49 -45 2.87 1.03 140 60 3.78 1.32
-40 -40 2.91 1.05 149 65 3.83 1.33
-31 -35 2.96 1.06 158 70 3.87 1.35
-22 -30 3 1.08 167 75 3.91 1.36
-13 -25 3.05 1.09 176 80 3.95 1.37
-4 -20 3.09 1.1 185 85 4 1.38
5 -15 3.13 1.12 194 90 4.04 1.4
14 -10 3.18 1.13 203 95 4.08 1.41
23 -5 3.22 1.15 212 100 4.12 1.42
32 0 3.27 1.16 221 105 4.16 1.43
41 5 3.31 1.17 230 110 4.21 1.45
50 10 3.35 1.19 239 115 4.25 1.46
59 15 3.4 1.2 248 120 4.29 1.47
68 20 3.44 1.21 257 125 4.33 1.48
77 25 3.48 1.23 266 130 4.37 1.49
86 30 3.53 1.24 275 135 4.41 1.51
95 35 3.57 1.25 284 140 4.45 1.52
104 40 3.61 1.27 293 145 4.5 1.53
113 45 3.66 1.28 302 150 4.54 1.54
122 50 3.7 1.29
