SPYDER MODEL 7 VAV CONTROLLER INSTALLATION INSTRUCTIONS
45 31-00475-01
Nickel Class B DIN 43760 Sensors
The characteristic of the nickel temperature sensor is
specified as per DIN 43760. The large Temperature
Coefficient of Resistance (TCR) of the Ni-RTD, 6178
ppm/K, offers greater sensitivity than other types of
RTD's. The electrical characteristic can be described by
the following equation:
R(T) = R0 (1+aT+bT2+cT4+dT6)
Coefficients:
• a = 5.485 x 10-3
• b = 6.650 x 10-6
• c = 2.805 x 10-11
• d =-2.000 x 10-17
T(R) = a´+b´(1+c´R)½ +d´R5+e´R7 dT < 0.12 K (higher order
equations on request)
Coefficients:
• a´= - 412.6
• b´= 140.41
• c´= 0.00764
• d´= - 6.25 x 10-17
• e´= -1.25 x 10-24
Tolerances:
• Class B (0.4+0.007 x |T|) in range from 32 °F (0
°C) to 320 °F (+160 °C) (0.4+0.028 x |T|) in range
from -67 °F (-55 °C) to 32 °F (0 °C)
Table 35 Characteristic of the Nickel Temperature Sensor is Specified as per DIN 43760
Temp.
[°F]
Temp.
[°C]
0 1 2 3 4 5 6 7 8 9
-76 -60 695.2 699.9 704.6 709.3 714 718.7 723.4 728.2 733 737.8
-58 -50 742.6 747.4 752.2 757 761.9 766.8 771.6 776.5 781.4 786.4
-40 -40 791.3 796.3 801.2 806.2 811.2 816.2 821.2 826.3 831.3 836.4
-22 -30 841.5 846.5 851.7 856.8 861.9 867 872.2 877.4 882.6 887.8
-4 -20 893 898.2 903.4 908.7 913.9 919.2 924.5 929.8 935.1 940.5
14 -10 945.8 951.2 956.5 961.9 967.3 972.7 978.2 983.6 989.1 994.5
32 0 1000 1005.5 1011 1016.5 1022 1027.6 1033.1 1038.7 1044.3 1049.9
50 10 1055.5 1061.1 1066.8 1072.4 1078.1 1083.8 1089.5 1095.2 1100.9 1106.6
68 20 1112.4 1118.1 1123.9 1129.7 1135.5 1141.3 1147.1 1153 1158.8 1164.7
86 30 1170.6 1176.5 1182.4 1188.3 1194.2 1200.2 1206.1 1212.1 1218.1 1224.1
104 40 1230.1 1236.1 1242.2 1248.2 1254.3 1260.4 1266.5 1272.6 1278.8 1284.9
122 50 1291.1 1297.2 1303.4 1309.6 1315.8 1322 1328.3 1334.5 1340.8 1347.1
140 60 1353.4 1359.7 1366 1372.4 1378.7 1385.1 1391.5 1397.9 1404.3 1410.8
158 70 1417.2 1423.7 1430.1 1436.6 1443.1 1449.7 1456.2 1462.8 1469.3 1475.9
176 80 1482.5 1489.1 1495.7 1502.4 1509.1 1515.7 1522.4 1529.1 1535.9 1542.6
194 90 1549.3 1556.1 1562.9 1569.7 1576.5 1583.4 1590.2 1597.1 1604 1610.9
212 100 1617.8 1624.7 1631.7 1638.6 1645.6 1652.6 1659.6 1666.7 1673.7 1680.8
230 110 1687.9 1695 1702.1 1709.3 1716.4 1723.6 1730.8 1738 1745.2 1752.5
248 120 1759.7 1767 1774.3 1781.6 1788.9 1796.3 1803.7 1811.1 1818.5 1825.9
266 130 1833.3 1840.8 1848.3 1855.8 1863.3 1870.9 1878.4 1886 1893.6 1901.2
284 140 1908.9 1916.5 1924.2 1931.9 1939.6 1947.4 1955.1 1962.9 1970.7 1978.5
302 150 1986.3 1994.2 2002.1 2010 2017.9 2025.9 2033.8 2041.8 2049.8 2057.8
320 160 2065.9 2074 2082.1 2090.2 2098.3 2106.5 2114.6 2122.8 2131.1 2139.3
