SPYDER MODEL 7 VAV CONTROLLER INSTALLATION INSTRUCTIONS
31-00475-01 42
20 K NTC Characteristics
Table 34 20 K NTC Characteristics
Temp.
[°F]
Temp.
[°C]
Resistance
[KΩ]
Terminal
voltage [V]
Temp.
[°F]
Temp.
[°C]
Resistance
[KΩ]
Terminal
Voltage [V]
-58 -50 1659 8.78 5 -15 164 7.83
-56.2 -49 1541 8.77 6.8 -14 154 7.78
-54.4 -48 1432 8.76 8.6 -13 146 7.72
-52.6 -47 1331 8.75 10.4 -12 137 7.66
-50.8 -46 1239 8.74 12.2 -11 130 7.6
-49 -45 1153 8.72 14 -10 122 7.53
-47.2 -44 1073 8.71 15.8 -9 116 7.46
-45.4 -43 1000 8.7 17.6 -8 109 7.39
-43.6 -42 932 8.69 19.4 -7 103 7.32
-41.8 -41 869 8.67 21.2 -6 97.6 7.25
-40 -40 811 8.66 23 -5 92.3 7.17
-38.2 -39 757 8.64 24.8 -4 87.3 7.09
-36.4 -38 706 8.62 26.6 -3 82.6 7.01
-34.6 -37 660 8.6 28.4 -2 78.2 6.93
-32.8 -36 617 8.58 30.2 -1 74.1 6.85
-31 -35 577 8.56 32 0 70.2 6.76
-29.2 -34 539 8.54 33.8 1 66.5 6.67
-27.4 -33 505 8.52 35.6 2 63 6.58
-25.6 -32 473 8.49 37.4 3 59.8 6.49
-23.8 -31 443 8.47 39.2 4 56.7 6.4
-22 -30 415 8.44 41 5 53.8 6.3
-20.2 -29 389 8.41 42.8 6 51.1 6.2
-18.4 -28 364 8.38 44.6 7 48.5 6.1
-16.6 -27 342 8.35 44.4 8 46 6
-14.8 -26 321 8.32 48.2 9 43.7 5.9
-13 -25 301 8.28 50 10 41.6 5.8
-11.2 -24 283 8.25 51.8 11 39.5 5.7
-9.4 -23 266 8.21 53.6 12 37.6 5.59
-7.6 -22 250 8.17 55.4 13 35.7 5.49
-5.8 -21 235 8.13 57.2 14 34 5.38
-4 -20 221 8.08 59 15 32.3 5.28
-2.2 -19 208 8.04 60.8 16 30.8 5.17
-0.4 -18 196 7.99 62.6 17 29.3 5.07
1.4 -17 184 7.94 64.4 18 27.9 4.96
3.2 -16 174 7.89 66.2 19 26.6 4.85
