SPYDER MODEL 7 VAV CONTROLLER INSTALLATION INSTRUCTIONS
49 31-00475-01
75.2 24 1093 0.42 145.4 63 1244 0.476
77 25 1097 0.422 147.2 64 1248 0.477
78.8 26 1101 0.423 149 65 1252 0.479
80.6 27 1105 0.425 150.8 66 1255 0.48
82.4 28 1109 0.426 152.6 67 1259 0.481
84.2 29 1113 0.428 154.4 68 1263 0.483
86 30 1117 0.429 156.2 69 1267 0.484
87.8 31 1121 0.431 158 70 1271 0.486
89.6 32 1124 0.432 159.8 71 1275 0.487
91.4 33 1128 0.433 161.6 72 1278 0.488
93.2 34 1132 0.435 163.4 73 1282 0.49
95 35 1136 0.436 165.2 74 1286 0.491
96.8 36 1140 0.438 167 75 1290 0.493
98.6 37 1144 0.439 168.8 76 1294 0.494
100.4 38 1148 0.441 170.6 77 1297 0.495
102.2 39 1152 0.442 172.4 78 1301 0.497
104 40 1155 0.443 174.2 79 1305 0.498
105.8 41 1159 0.445 176 80 1309 0.499
107.6 42 1163 0.446 177.8 81 1313 0.501
109.4 43 1167 0.448 179.6 82 1317 0.502
111.2 44 1171 0.449 181.4 83 1320 0.503
113 45 1175 0.451 183.2 84 1324 0.505
114.8 46 1179 0.452 185 85 1328 0.506
116.6 47 1182 0.453 186.8 86 1332 0.508
118.4 48 1186 0.455 188.6 87 1336 0.509
120.2 49 1190 0.456 190.4 88 1339 0.51
122 50 1194 0.458 192.2 89 1343 0.512
123.8 51 1198 0.459 194 90 1347 0.513
125.6 52 1202 0.461 195.8 91 1351 0.515
127.4 53 1205 0.462 197.6 92 1355 0.516
129.2 54 1209 0.463 199.4 93 1358 0.517
131 55 1213 0.465 201.2 94 1362 0.519
132.8 56 1217 0.466 203 95 1366 0.52
134.6 57 1221 0.467 204.8 96 1370 0.522
136.4 58 1225 0.469 206.6 97 1374 0.523
138.2 59 1229 0.47 208.4 98 1377 0.524
140 60 1232 0.471 210.2 99 1381 0.525
141.8 61 1236 0.473 212 100 1385 0.527
143.6 62 1240 0.474 213.8 101 1389 0.528
Table 39 PT1000 Characteristics (Continued)
Temp.
[°F]
Temp.
[°C]
Resistance
[KΩ]
Terminal
Voltage [V]
Temp.
[°F]
Temp.
[°C]
Resistance
[KΩ]
Terminal
Voltage
[V]
