11
2. KM-160BAJ
Pump Motor
Water Tank
Compressor
Water Circuit
Refrigeration Circuit
Drain Valve
Drain Outlet
Hot Gas
Valve
Drier
Expansion Valve
Evaporator
Fan
Condenser
Spray Tube
Water Valve
Water Inlet
Float Switch
Cleaning Valve
Thermistor
Pressure
Switch
Strainer
