55
VIII. Technical Information
A. Specifi cation Data
1. KM-80BAJ
AC SUPPLY VOLTAGE 115/60/1
AMPERAGE 3.5 A ( 5 Min. Freeze AT 104°F / WT 80°F)
MINIMUM CIRCUIT AMPACITY 15 A
MAXIMUM FUSE SIZE 15 A
APPROXIMATE ICE PRODUCTION Ambient WATER TEMP. (°F)
PER 24 HR. Temp.(°F) 50 70 90
lbs./day ( kg/day ) 70 *80 (36) 74 (34) 68 (31)
Reference without *marks 80 76 (34) 66 (30) 61 (28)
90 74 (34) *60 (27) 54 (25)
100 74 (33) 59 (27) *49 (22)
SHAPE OF ICE Crescent Cube
ICE PRODUCTION PER CYCLE 1.7 lbs. (0.75kg) 80 pcs.
APPROXIMATE STORAGE CAPACITY 38 lbs. (17kg)
ELECTRIC & WATER CONSUMPTION 90/70°F 70/50°F
ELECTRIC W (kWH/100 lbs.) 200(7.95) 200(5.98)
WATER gal./24HR (gal./100 lbs.) 11(18.2) 16(20.5)
ENERGY STAR 3.0 YES
EXTERIOR DIMENSIONS 17.72" x 24" x 39" (452 x 617 x 990 mm)
(WxDxH) Including 6" Adjustable legs
EXTERIOR FINISH Stainless Steel, Galvanized Steel (Rear)
WEIGHT Net 92 lbs. (42 kg), Shipping 123 lbs. (56 kg)
CONNECTIONS - ELECTRIC Cord Connection
- WATER SUPPLY Inlet 1/2" FPT
- DRAIN Outlet 3/4" FPT
CUBE CONTROL SYSTEM Float Switch
HARVESTING CONTROL SYSTEM Hot Gas and Water, Thermistor and Timer
ICE MAKING WATER CONTROL Timer Controlled. Overflow Pipe
COOLING WATER CONTROL N/A
BIN CONTROL SYSTEM Mechanical Level Switch with Delay
COMPRESSOR Hermetic, Model QA51K13GAU6-E0GS
CONDENSER Air-Cooled, Fin and tube type
EVAPORATOR Vertical type, Stainless Steel and Copper
REFRIGERANT CONTROL Capillary Tube
REFRIGERANT CHARGE R-134a 7.1oz (200g)
DESIGN PRESSURE High 290PSIG, Low 130PSIG
P.C. BOARD CIRCUIT PROTECTION High/Low Voltage Cut-out ( Internal )
COMPRESSOR PROTECTION Auto-reset Overload Protector ( Internal )
REFRIGERANT CIRCUIT PROTECTION Auto-reset High Pressure Control Switch
LOW WATER PROTECTION Float Switch
ACCESSORIES -SUPPLIED Ice Scoop, 6" Adjustable Leg(4pcs.)
-REQUIRED N/A
OPERATING CONDITIONS VOLTAGE RANGE 104 - 127 V
AMBIENT TEMP. 45 -100° F
WATER SUPPLY TEMP. 45 - 90° F
WATER SUPPLY PRESSURE 10 - 113 PSIG
DRAWING NO. (DIMENSION) N/A
