40
Dip Switch Setting
Frequency
No. 5 No. 6
OFF OFF every cycle
ON OFF every 2 cycles
OFF ON every 5 cycles
ON ON every 10 cycles
5. Harvest Pump Timer (S1 dip switch 7 & 8)
The harvest pump timer allows the water valve to close and the pump motor to circulate
water in the tank during the ¿ nal part of harvest. The water valve is open during harvest
for a maximum of 6 minutes or the length of harvest minus 0, 10, 30, or 50 seconds
(determined by the harvest pump timer setting), whichever is shorter. When the water
valve closes, the pump motor energizes and runs for the time determined by the harvest
pump timer setting.
The harvest pump timer is factory-adjusted, and no adjustment is required.
Dip Switch Setting
Time
(seconds)
No. 7 No. 8
OFF OFF 0
ON OFF 10
OFF ON 30
ON ON 50
6. Freeze Timer (S1 dip switch 9 & 10)
NOTICE
Adjust to proper speci¿ cation, or the unit may not operate correctly.
The freeze timer setting determines the maximum allowed freeze time to prevent
possible freeze-up issues. Upon termination of freeze timer, machine initiates the
harvest cycle. After 2 consecutive timer terminations, machine will shut down, possibly
indicating a problem.
The freeze timer is factory adjusted, and no adjustment is required.
Dip Switch Setting
Time
(minutes)
No. 9 No. 10
OFF OFF 60
ON OFF 50
OFF ON 70
ON ON 100
7. Pump-Out/Drain Selector (S2 dip switch 1)
The pump-out/drain selector setting determines whether the pump motor energizes
To Next Page
