22
Fig. 4
Reed Switch Lead Hook
Case Actuator Reed Switch Cover
Stopper B [both sides]
* Fits in Stopper A
Stopper A [both sides]
Slide Rail
[both sides]
Pull
Fig. 3
Retainer
Evaporator
Pump Motor
Hold here and pull towards you
