INSTALLATION MANUAL 15
Heat shield
CombiSlim II
LOW + HIGH Temperature Environment
At least 50 mm / 2 inches clearance from the rear, left and right
sides is required.
100mm /4 inches clearance above the oven is required.
Do not place excessive heat sources such as hot plates, frying
pans, fryers and other sources of strong heat near the oven. The
minimum distance to such appliances must be 400 mm.
Failure to comply may invalidate the oven warranty.
If the temperature on the right side of the oven is too high, a safety
shut down can occur.
Number Equipment Oven Type
30200086 Heat shield 1.06
30200088 Heat shield 1.10
30200090 Heat shield 1.16
30200091 Heat shield 1.20
30200092 Heat shield 2.10
30200094 Heat shield 2.20
