34 INSTALLATION MANUAL
RINSE AND DETERGENT CONNECTION
The detergent and rinse connections are marked with a red and blue dot.
Thise marks are on all ovens, no matter the oven type, model and size.
Visual Cooking II Smart Edition
Detergent and rinse conection.
• At the bottom of the oven near the rear, connect the blue hose to the fitting with
the blue sticker and to the rinse aid container.
• At the bottom of the oven near the rear, connect the red hose to the fitting with the
red sticker and to the detergent container.
• The length of the hose for detergent and rinse may never exide 130CM.
• If there is a need for hoses longer then 130CM to the detergent and rinse canisters,
a CombiWash Logistig system is required.
Do not place the containers above the bottom of oven.
Detergent Rinse
