INSTALLATION MANUAL 33
POWER CONFIGURATION 1.10
Configuration Element Power Phase Power KW Hz Amp Fuse Cable size MM2
1.
- 208/230/240 3AC 10,4/12,7/13,8 50/60 35 50 6
- 208/230/240 3NAC 10,4/12,7/13,8 50/60 35 50 6
- 400/415 3NAC 12,7/13,8 50/60 21 25 4
2. - 400/415 3AC 12,7/13,8 50/60 21 25 4
3. - 440/480 3AC 10,4/12,4 50/60 19 25 4
