18 INSTALLATION MANUAL
WATER SUPPLY LINES AND FILTERS
Oven located in areas where raw water have specifications do not require filtration. No
filter and only one supply line is needed.
For this non-filter option a manifold (1) is fitted to the two water inlet ports of the valves and
from the manifold directly to the water outlet of the kitchen.
Combislim oven have one water valve/inlet (1). This is for all water functions; wash, steam
and drain cooling. The hand shower is connected directly to the water supply with a T-fitting.
COMBISLIM II.
No filter
VISUAL COOKING II SE.
No filter.
VISUAL COOKING II SE COMBIPLUS.
No filter.
w
w
w
w
1
1
