INSTALLATION MANUAL 43
Attachment Plate
(secure with leg mount
bolt)
Gas Hose
Quick Connect
Gas Supply Line
Restraint
IMPORTANT: Cable restraint should be fastened as close as possible to the flexible
connector and short enough to prevent any strain on the flexible connector.
At maximum stretch of shortened restraint, the flexible connector should be easy to
install and quick to connect.
Installation of Gas Hose and Restraint
(Single Section Shown)
Gas Hose Restraint
