INSTALLATION MANUAL 45
MISCELLANEOUS TOOLS
• Flat-headed screwdriver, size 1.0 x 5.5, used for adjusting the maximum setting on
the gas valve.
• Flat-headed screwdriver, size 0.6 x 3.5, used for the gas-test nipple when measuring
the gas pressure on the gas valve.
• Allen key, size 2 mm, for fine-adjusting the oset governor (minimum) setting on
the gas valve and for adjusting the maximum setting on the gas valve
The oset governor (minimum) must only be fine- adjusted during
adjustment of the O
2
% and must never be turned before the oven is
running and the maximum screw is adjusted.
