Removal and Replacement Procedures
Maintenance and Service Guide 5–31
5.14 Security Module (TPM)
1. Prepare the notebook for disassembly (refer to Section 5.3).
2. Remove the keyboard (refer to Section 5.9).
3. Remove the switch cover (refer to Section 5.12).
4. Remove the keyboard plate (refer to Section 5.13).
5. Remove the PM3.5×3.0 screw 1 that secures the security
card to the system board.
6. Lift the security module straight up 2 to disconnect it from
the system board.
Removing the Security Module
Reverse the above procedure to install the security card.
Spare Part Number Information
Security Module (TPM) 345856-001

HP Compaq nc6000 - Notebook PC Specifications

General

Processor	Intel Pentium M
Chipset	Intel 855PM
Storage	30 GB to 60 GB HDD
Hard Drive Interface	ATA-100
Battery	6-cell Lithium-Ion
Operating System	Windows XP Professional
RAM	256 MB, upgradable to 2 GB
Graphics	ATI Mobility Radeon 9600
Display	14.1-inch
Display Resolution	1024 x 768 or 1400 x 1050
Optical Drive	DVD-ROM, CD-RW/DVD Combo, or DVD±RW
Networking	10/100/1000 Ethernet
Ports	2 x USB 2.0, VGA, parallel, serial, headphone, microphone
