5–40 Maintenance and Service Guide
Removal and Replacement Procedures
5.18 Display Assembly
1. Prepare the notebook for disassembly (refer to Section 5.3).
2. Disconnect the wireless antenna cables from the Mini PCI
communications board (refer to Section 5.5).
3. Remove the following components:
❏ Keyboard (refer to Section 5.9)
❏ Memory shield (refer to Section 5.11)
❏ Switch cover (refer to Section 5.12)
❏ Keyboard plate (refer to Section 5.13)
❏ Fan assembly (refer to Section 5.15)
❏ Heat sink (refer to Section 5.16)
Spare Part Number Information
Display assemblies
14.1-inch, TFT, SXGA+
14.1-inch, TFT, XGA
344397-001
344396-001
To Next Page
