5–28 Maintenance and Service Guide
Removal and Replacement Procedures
5.12 Switch Cover
1. Prepare the notebook for disassembly (refer to Section 5.3).
2. Remove the keyboard (refer to Section 5.9).
3. Close the notebook.
4. Turn the notebook upside down, with the rear panel
facing you.
5. Remove the two TM2.5×9.0 screws that secure the switch
cover to the notebook.
Removing the Switch Cover Screws
Spare Part Number Information
Switch cover 344400-001
To Next Page
