Removal and Replacement Procedures
Maintenance and Service Guide 5–3
5.2 Disassembly Sequence Chart
Use the chart below to determine the section number to be
referenced when removing notebook components.
Disassembly Sequence Chart
Section Description
# of Screws
Removed
5.3 Preparing the notebook for disassembly
Battery pack
Hard drive
0
2 to remove,
6 to disassemble
5.4 Notebook feet 0
5.5 Mini PCI communications board 1
5.6 MultiBay device 0
5.7 Bluetooth wireless communications
board
3
5.8 Integrated smart card 0
5.9 Keyboard 2
5.10 Modem board 2
5.11 Memory expansion board 0
5.12 Switch cover 2
5.13 Keyboard plate 0
5.14 Security Module (TPM) 1
5.15 Fan assembly 5
5.16 Heat sink 4
5.17 Processor 0
5.18 Display assembly 4
5.19 Top cover 16
5.20 RTC battery 0
