5–4 Maintenance and Service Guide
Removal and Replacement Procedures
Section Description
# of Screws
Removed
5.21 LED board 0
5.22 Button board 2
5.23 System board 5 screws,
2 standoffs
Disassembly Sequence Chart (Continued)
