5–26 Maintenance and Service Guide
Removal and Replacement Procedures
5.11 Memory Expansion Board
1. Prepare the notebook for disassembly (refer to Section 5.3).
2. Remove the keyboard (refer to Section 5.9).
3. Lift the left side of the memory shield and swing it up and to
the right 1 until it rests at a 45-degree angle.
4. Slide the shield to the left 2 to remove it.
✎
The memory shield is included in the Miscellaneous Plastics Kit,
spare part number 344411-001.
Removing the Memory Shield
Spare Part Number Information
Memory expansion boards, 333-MHz
1024-MB DDR
512-MB DDR
256-MB DDR
336579-001
336578-001
336577-001

HP Compaq nc6000 - Notebook PC Specifications

General

Processor	Intel Pentium M
Chipset	Intel 855PM
Storage	30 GB to 60 GB HDD
Hard Drive Interface	ATA-100
Battery	6-cell Lithium-Ion
Operating System	Windows XP Professional
RAM	256 MB, upgradable to 2 GB
Graphics	ATI Mobility Radeon 9600
Display	14.1-inch
Display Resolution	1024 x 768 or 1400 x 1050
Optical Drive	DVD-ROM, CD-RW/DVD Combo, or DVD±RW
Networking	10/100/1000 Ethernet
Ports	2 x USB 2.0, VGA, parallel, serial, headphone, microphone
