HP Compaq nc6000 - Notebook PC - Page 120

5–34 Maintenance and Service Guide
Removal and Replacement Procedures
9. Remove the three PM2.0×3.0 screws 1 that secure the fan
to the fan housing.
10. Remove the fan 2.
Removing the Fan from the Fan Assembly
Reverse the above procedure to install the fan assembly.
