6–4 Maintenance and Service Guide
Specifications
Table 6-3
14.1-inch, XGA, TFT Display
Dimensions
Height
Width
Diagonal
28.6 cm
21.4 cm
35.7 cm
11.2 in
8.4 in
14.1 in
Number of colors up to 16.8 million
Contrast ratio 250:1
Refresh rate 60 Hz
Brightness 180 nits typical
Pixel resolution
Pitch
Format
Configuration
0.279 × 0.279 mm
1024 × 768
RGB stripe
Backlight CCFT
Character display 80 × 25
Total power
consumption
4 W
Viewing angle +/-40° horizontal, +20/-40° vertical typical
