Screw Listing
Maintenance and Service Guide C–15
Torx T8M2.5×9.0 Screw Locations
Table C-10
Torx T8M2.5×9.0 Screw
Color Qty. Length Thread
Head
Width
Black 15 9.0 mm 2.5 mm 5.0 mm
Where used:
1 Two screws that secure the switch cover to the notebook
(documented in Section 5.12)
2 Four screws that secure the display assembly to the notebook
(documented in Section 5.18)
mm
