Product Description
Maintenance and Service Guide 1–23
Table 1-6
Top Components
(Continued)
Item Component Function
8 Presentation Mode
button
Alternates between presentation modes.
9 Pointing stick Moves the pointer and selects or activates
items on the screen.
10 Left and right pointing
stick buttons
Function like the left and right mouse
buttons on an external mouse.
11 TouchPad Moves the pointer and selects or activates
items on the screen.
12 Left and right
TouchPad buttons
Function like the left and right buttons on an
external mouse.
13 MultiBay light On: A device in the MultiBay is being
accessed.
14 Hard drive light On: Hard drive in the hard drive bay is being
accessed.
15 Battery light On: A battery pack is charging.
Blinking: A battery pack that is the only
available power source has reached a
low-battery condition. When the battery
reaches a critical low-battery condition, the
battery light begins blinking more quickly.
16 Power/Standby light On: Power is turned on.
Blinking: Notebook is in Standby. The
power/Standby light also blinks when a
battery pack that is the only available
power source reaches a critical low-battery
condition. The light goes off when the
system enters Hibernation or shuts down.
17 Wireless on/off light On: An integrated wireless device has been
enabled.
