HP Compaq nc6000 - Notebook PC User Manual

5–10 Maintenance and Service Guide
Removal and Replacement Procedures
Ä
CAUTION: The hard drive should be disassembled only if it is
damaged and must be repaired. Unnecessary disassembly of the hard
drive can result in damage to the hard drive and loss of information.
g. Remove the two T5M3.0×4.0 screws 1 and the two
PM3.0×3.5 screws 2 that secure the hard drive to the
hard drive frame.
h. Use a 4.0-mm socket to remove the two M2.0×10.0
alignment pins 3 that secure the hard drive to the hard
drive frame.
i. Remove the hard drive from the hard drive frame 4.
j. Remove the hard drive connector from the hard drive 5.
Removing the Hard Drive Bracket and Connector
Reverse the above procedure to reassemble and install the
hard drive.

HP Compaq nc6000 - Notebook PC Specifications

General

Processor	Intel Pentium M
Chipset	Intel 855PM
Storage	30 GB to 60 GB HDD
Hard Drive Interface	ATA-100
Battery	6-cell Lithium-Ion
Operating System	Windows XP Professional
RAM	256 MB, upgradable to 2 GB
Graphics	ATI Mobility Radeon 9600
Display	14.1-inch
Display Resolution	1024 x 768 or 1400 x 1050
Optical Drive	DVD-ROM, CD-RW/DVD Combo, or DVD±RW
Networking	10/100/1000 Ethernet
Ports	2 x USB 2.0, VGA, parallel, serial, headphone, microphone
