LABel
Command Syntax:
:MACHine{l i2):SFORmat:iABel c name > [, {c polarity> i cassignment>)]...
where:
c name > :: = string of up to 6 alphanumeric characters
< polarity > :: = {POSitive 1 NEGative)
c assignment > :: = format (integer from 0 to 65535) for a pod (pods are assigned in decreasing order)
Examples: OUTPUT XXX;“:MACHINEZ:SFORMAT:LABEL ‘STAT’, POSITIVE, 65535,127,40312”
OUTPUT XXX;“:MACHINE2:SFORMAT:LABEL ‘SIG l’, 64, 12. 0. 20, NEGATIVE”
OUTPUT XXX;“:MACHINEl:SFORMAT:LABEL ‘ADDR’, NEG, #B0011110010101010”
Query Syntax:
:MACHine{ 1 iP}:SFORmat:LABel? c name >
Returned Format:
[:MACHine{ 1)2}:SFORmat:LABel] c name > , c polarity> [, <assignment >I... -z NL>
Example: 10 DIM String$[lDO]
20 OUTPUT XXX;“:MACHINE2:SFORMAT:LABEL? ‘DATA”’
30 ENTER XXX String$
40 PRINT String$
50 END
HP 1650B/HP 16518
Programming Reference
SFORmat Subsystem
11-7
