System LEDs
Point to the System LEDs area to view information about the following LEDs:
• Power (Green)
On—The switch is receiving power.◦
◦ Off—The switch is NOT receiving power.
• Fault (Orange)
Blinking—A fault has occurred, other than during self-test.◦
◦ On—Self-test in progress.
◦ Off—The switch is operating properly.
• Locator (Blue)
Blinking—The switch is in Locate mode, attempting to locate a specific switch.◦
◦ Off—The locator is disabled. This mode can be enabled using the Web interface. See
“Locator” (page 57).
Port LEDs
Each 10/100/1000 Mbps RJ45 port has two single color LEDs to indicate the, Link/Activity on
the Left port LED and the Speed status indicated by the Right port LED.
The left-port LED indicates link status, as follows:
• On—The port is enabled and receiving a link indication or other signal from the connected
device.
• Blinking—The port has network activity.
• Off—The port has no active network cable connected, is not receiving link signal, or is disabled.
The right-port LED indicates speed status, as follows:
• On—The port is operating continuously at 1000 Mbps.
• Blinking—The port is operating at 100 Mbps.
• Off—The port is operating at 10 Mbps.
NOTE: The PD LEDs on the HP1810-8G glow when the switch is powered via the PD Port 1 using
an external PoE device.
Getting started with the web interface 11
