HP 1810-8G User Manual

Table 1 Log Page (continued)
DescriptionField
The current time in hours, minutes and seconds as configured(24 or 12-hr AM/PM format) by the
user.
Current Time
The current date in month, day, and year format.Date
NOTE: The System Name, System Location, and System Contact accept all alphanumeric
characters including hyphens, commas and spaces.
Log Status page
The Log Status page displays logged system messages, such as configuration failures and user
sessions. The log page displays the 100 most recent log entries. The newest log entry, by default,
is displayed at the bottom of the list.
NOTE: If more than 100 logs accumulate, their Log Index numbers continue to increment beyond
100 and the oldest entries are deleted (for example, if 200 log entries were generated since the
system was last restarted or the log file was cleared, then the log file would display entries
101–200).
To display the Log status page, click Status > Log in the navigation pane.
Figure 5 Log Status page
• Click the arrows next to the column headings to sort the list by the column, in ascending or
descending order.
• Click Clear to delete all log messages.
• Click the Refresh link above the page to re-display the page with new logs.
Table 2 System Description Fields
DescriptionField
Total number of log messages reported during System up time.Total Number of Messages
Log Message
Log number in the log table.Log Index
Severity associated with the log message.Severity
Time at which the log was entered in the table.Log Time
Log Status page 13

HP 1810-8G Specifications

General

Switching Capacity	16 Gbps
Throughput	11.9 Mpps
MAC Address Table Size	8000 entries
Jumbo Frame Support	Yes
PoE	No
Weight	2.2 lb (1 kg)
Ports	8 x 10/100/1000
Form Factor	Desktop, Rack-mountable
Management	Web-based
Power Supply	External
Operating Temperature	0°C to 40°C
Operating Humidity	15% to 95% non-condensing
