HP 1810-8G User Manual

Table 2 System Description Fields (continued)
DescriptionField
Component from which the massage was logged.Component
Description of the entry.Description
For information on configuring log settings, see “Log Configuration” (page 54).
Port Summary page
The Port Summary page displays a summary of network traffic from the ports. This summary can
be used to identify potential problems with the switch. It also helps to identify what has been
configured on this port. The displayed values are accumulated after the last clear operation.
Refreshing the page shows the latest statistics, which provide per-port statistics on packets transmitted
and received for all the ports. Scroll down the page to view the Port Statistics table, which provides
per-port statistics on packets transmitted and received.
To display the Port Summary page, click Status > Port Summary in the navigation pane.
A configuration summary and status of all physical and logical ports are displayed in Figure 6.
Figure 6 Port Summary Page
14 Status Pages

HP 1810-8G Specifications

General

Switching Capacity	16 Gbps
Throughput	11.9 Mpps
MAC Address Table Size	8000 entries
Jumbo Frame Support	Yes
PoE	No
Weight	2.2 lb (1 kg)
Ports	8 x 10/100/1000
Form Factor	Desktop, Rack-mountable
Management	Web-based
Power Supply	External
Operating Temperature	0°C to 40°C
Operating Humidity	15% to 95% non-condensing
