HP 1810-8G User Manual

Table 3 Port Summary Fields
DescriptionField
Port Summary
List of physical and logical interfaces supported or configured on a particular
platform.
Interface
Displays whether the port is operating in copper mode or fiber mode.Physical Type
The physical status (up or down) of the link at the port.Port Status
Displays whether Auto negotiation is enabled or disabled on the port.AutoNeg Status
The physical speed at which the port is operating.Link Speed
The Maximum Transmission Unit (MTU), also referred to as Max Frame size
acceptable on the specified port.
MTU
Port Statistics and Trunk Statistics
NOTE: The following statistics are collected for both individual port and for trunks.
List of physical and logical interfaces supported on that platform.Interface/Trunk
The packet count received on the port with out any packet errors.Received Packets w/o Error
The packet count received on the port with errors.Received Packets with Error
The packet count for Broadcast packets received on the port.Broadcast Received Packets
The number of packets transmitted out of that port with out any packet errors.Transmitted Packets w/o Errors
The number of packets transmitted out of the port with packet errors.Transmitted Packets with Errors
The number of packet collisions.Collisions
The number of Ethernet pause frames transmitted. (This information is collected
for ports but not for trunks.)
Transmitted Pause Frames
The number of Ethernet pause frames received. (This information is collected
for ports but not for trunks.)
Received Pause Frames
• Click Clear to reset all statistics to their initial values.
• Click the Refresh link above the page to re-display the page with the latest port information.
For instructions on configuring port settings, see “Port Configuration” (page 31).
LLDP Statistics page
The Link Layer Discovery Protocol (LLDP) Statistics page displays summary and per-port information
for LLDP frames transmitted and received on the switch.
To display the LLDP Statistics page, click Status > LLDP Statistics in the navigation pane.
LLDP Statistics page 15

HP 1810-8G Specifications

General

Switching Capacity	16 Gbps
Throughput	11.9 Mpps
MAC Address Table Size	8000 entries
Jumbo Frame Support	Yes
PoE	No
Weight	2.2 lb (1 kg)
Ports	8 x 10/100/1000
Form Factor	Desktop, Rack-mountable
Management	Web-based
Power Supply	External
Operating Temperature	0°C to 40°C
Operating Humidity	15% to 95% non-condensing
