Table 7 Loop Protection Fields
DescriptionField
List of ports with loop protection currently enabled.Interface
The action that is set to occur when a loop is detected on the port with Loop Protection
enabled:
Configured Action Taken
Shutdown port—The port will be shut down for the configured period.
Log—The event will be logged and the port remains operational.
Shutdown and log—The event will be logged and the port it shut down for the
configured period.
Shows whether the port is configured to forward packets to the multicast destination
MAC address designated for the Loop Protection feature.
Tx Mode
The number of loops detected on this interface since the last system boot or since statistics
were cleared.
Loop Count
The current loop protection status of the port.Status
Whether a loop is currently detected on the port.Loop
The time of the last loop event detected.Time of Last Loop
Click Clear to reset all counters to 0.
Click the Refresh link above the page to re-display the page with the latest status from the
For instructions on configuring this feature and a description of these fields, see “Loop Protection
(page 35).
Spanning Tree Status page
The Spanning Tree Status page displays the global bridge configuration and the per-port spanning
tree states.
To display the Spanning Tree page, click Status > Spanning Tree in the navigation pane.
Figure 11 Spanning Tree Status page
Spanning Tree Status page 19
