HP 425 - Mounting the AP on a ceiling

10
Figure 12 Mounting the AP to the T-rail
(1) M4 × 5 screw (2) Mountin
g
hook (3) Mountin
g
clip (4) Hook
Mounting the AP on a ceiling
CAUTION:
• Verify that the AP is secured to the mounting bracket to avoid falloff.
• Do not use this method to mount the AP to a location made of low-intensity materials such as a plaster
ceiling. If this installation method is required in such an environment, put a high-intensity plate beneath
the ceiling to secure the installation.
• The ceiling tiles must be less than 18 mm (0.71 in) thick, and the ceiling must be able to bear a wei
g
h
t
of at least 5 kg (11.02 lb).
The three bolt holes are needed for mounting the AP on a ceiling as shown in Figure 13.
4
3
2
1
