Chapter 4 Command Reference
Introduction
Programming Guide 4-103
[:SENSe]:TINTerval:ARM:ESTOP[:LAYer[1]]:SOURce IMMediate
| TIMer | INTernal2
Sets or queries the stop arm for Time Interval measurements.
A sequence of ASCII-encoded bytes: IMM or TIM or INT2
• *RST: IMMediate
• The [:SENS]:TINT:ARM:ESTOP[:LAYer[1]]:SOUR command has no affect
on the following measurements: Risetime, Falltime, Duty Cycle, and Pulse
Width.
Gate & ExtArm
[:SENSe]:TINTerval:ARM:ESTOP[:LAYer[1]]:TIMer
<numeric_value> [S]
Sets or queries the time used to delay the stop arm for Time Interval
measurements.
For short delay: 100E-9 to 0.999,999,9 seconds
For long delay: 1.000 to 10.000 seconds
For short delay: 100E-9 seconds
For long delay: 1E-3 seconds
Numeric data transferred as ASCII bytes in <NR1> format.
• *RST: 100E-9 S
• Only applies when [:SENS]:TINT:ARM:ESTOP[:LAYer[1]]:SOUR TIM is
selected.
• The [:SENS]:TINT:ARM:ESTOP[:LAYer[1]]:TIM command has no affect
on the following measurements: Risetime, Falltime, Duty Cycle, and Pulse
Width.
Gate & ExtArm
Query Response
Comments
Related
Front-Panel
Keys
<numeric_value>
Range
<numeric_value>
Resolution
Query Response
Comments
Related
Front-Panel
Keys
