HP 54753A User Manual

Specifications and Characteristics
Vertical Specifications
12-4
Vertical Specifications
Bandwidth (
−
3 dB) dc to 12.4 or 18.0 GHz
1
, user selectable
dc to 12.4 or 20.0 GHz, user selectable
2
dc Accuracy—single marker
3 4 5
12.4 GHz bandwidth
±
0.4% of full scale
±
2 mV
±
0.6% of reading-channel offset
6
±
(1%/°C) (
∆
T
cal
) (reading)
7
18 GHz bandwidth
±
0.4% of full scale
±
2 mV ±1.2% of reading-channel offset
6
±
(1%/°C) (
∆
T
cal
) (reading)
7
20 GHz bandwidth
2
±
0.4% of full scale
±
2 mV ±1.2% of reading-channel offset
6
±
(1%/°C) (
∆
T
cal
) (reading)
7
dc Difference—two marker accuracy on same channel
3 5
12.4 GHz bandwidth
±
0.8% of full scale
±
0.6% of delta reading
6
±
(1%/°C) (
∆
T
cal
) (delta reading)
7
18 GHz bandwidth
±
0.8% of full scale
±
1.2% of delta reading
6
±
(1%/°C) (
∆
T
cal
) (delta reading)
7
20 GHz bandwidth
2
±
0.8% of full scale
±
1.2% of delta reading
6
±
(1%/°C) (
∆
T
cal
) (delta reading)
7
Transition Time (10%–90%)
(characteristic)
, calculated from T=0.35/BW, electrical
12.4 GHz bandwidth
28.2 ps (characteristic)
18 GHz bandwidth
19.4 ps (characteristic)
20 GHz bandwidth
2
17.5 ps (characteristic)
RMS Noise, Maximum
12.4 GHz 0.5 mV
(0.25 mV characteristic)
18 GHz 1.0 mV
(0.5 mV characteristic)
20 GHz
2
1.0 mV
(0.5 mV characteristic)
Scale Factor, full scale is eight divisions
Minimum 1 mV/div
Maximum 100 mV/div
Display Resolution 256 points
