Specifications and Characteristics
Power Requirements
12-6
Power Requirements
Supplied by mainframe.
Weight
Characteristics
The following characteristics are typical for the HP 54753A and 54754A TDR
plug-in modules. See the HP 54701A Active Probe Service Guide for complete
probe characteristics.
Trigger Input Characteristics
Refer to the HP 83480A, 54750A User’s Guide for Trigger specifications. The
HP 54753A/4A may affect the trigger sensitivity for trigger signals above
2.5 GHz.
Net approximately 1.1 kg (2.4 lb.)
Shipping approximately 2.0 kg (4.4 lb.)
Characteristic Impedance
50 [ohm ]
Input Connector 3.5 mm (m)
Trigger Level Range
±
1 V
Maximum Safe Input Voltage
±
2 Vdc + ac peak (+16 dBm)
Percent Reflection
≤
10% for 200 ps rise time
