HP 54754A TDR/TDT Setup Menu
Preset TDR/TDT
5-29
Table 5-10
Common Mode Stimulus Preset TDR/TDT Configuration
Key Path TDR/TDT Setup
Preset TDR/TDT
Menu Menu Item Set To
Acquisition Averaging on
Best Flatness
Time Base Scale 500.0 ps/div
Position Set to a value which places the
incident edge on screen.
Channel 1 Setup Display on
Scale 100 mV/div
Offset 200.0 mV
Bandwidth 12.4 GHz (for Stimulus on)
18.0 GHz (for Stimulus external)
Attenuation units ratio
Attenuation 1.000 : 1
Channel 2 Setup Scale 100 mV/div
Offset 200.0 mV
