100
Ste
Command
Remarks
11. Create an SNMPv3 user.
• In non-FIPS mode:
snmp-agent usm-user v3
user-name group-name [ remote
{ ip-address | ipv6
ipv6-address } [ vpn-instance
vpn-instance-name ] ] [ { cipher
| simple } authentication-mode
{ md5 | sha } auth-password
[ privacy-mode { aes128 |
des56 } priv-password ] ] [ acl
acl-number | acl ipv6
ipv6-acl-number ] *
• In FIPS mode:
snmp-agent usm-user v3
user-name group-name [ remote
{ ip-address | ipv6
ipv6-address } [ vpn-instance
vpn-instance-name ] ] { cipher |
simple } authentication-mode
sha auth-password
[ privacy-mode aes128
priv-password ] [ acl acl-number
| acl ipv6 ipv6-acl-number ] *
If the cipher keyword is specified,
the arguments auth-password
and priv-password are used as
encrypted keys.
To send informs to an SNMPv3
NMS, you must configure the
remote ip-address option to
specify the IP address of the
NMS.
12. (Optional.) Create an SNMP
context.
snmp-agent context context-name
By default, no SNMP context is
configured on the device.
13. (Optional.) Configure the
maximum SNMP packet size
(in bytes) that the SNMP agent
can handle.
snmp-agent packet max-size
byte-count
By default, the maximum SNMP
packet size that the SNMP agent
can handle is 1500 bytes.
14. (Optional.) Specify the UDP
port for receiving SNMP
packets.
snmp-agent port port-number
By default, the device uses UDP
port 161 for receiving SNMP
packets.
Configuring SNMP logging
The SNMP agent logs Get requests, Set requests, Set responses, and SNMP notifications, but does not
log Get responses.
• Get operation—The agent logs the IP address of the NMS, name of the accessed node, and node
OID.
• Set operation—The agent logs the NMS' IP address, name of accessed node, node OID, variable
value, and error code and index for the Set operation.
• Notification tracking—The agent logs the SNMP notifications after sending them to the NMS.
To configure SNMP logging:
Ste
Command
Remarks
1. Enter system view.
system-view N/A
